Gauge
Name Description
VLT Battery Voltage Normal running battery voltage is between 13 and 15. When the
engine is off it should be between 11 and 13. Voltages higher than
15 volts can damage batteries and electrical components. Voltages
below 13 when the vehicle is running could indicate poor charging of
the battery. Voltage below 11 when the engine is off could indicate a
low battery charge or a shorted battery cell.
FIA
CIA
F˚-IntakeAirTemperature
C˚-IntakeAirTemperature
Temperature of the air going into the engine. At highway speeds,
this will typically be a few degrees higher than the outside air
temperature. At idle or low speed, it may be much higher in
temperature than the outside temperature due to the low airflow into
the engine and the high under-hood temperatures warming it up.
TFT Transmission Fluid
Temperature
ThisindicatesthetransmissionfluidtemperatureineitherF˚orC˚as
selected in the setup procedure
GPH
LPH
Gallons Per Hour
Liters Per Hour
Fuel consumption rate in the selected units. This is sensitive to
throttle, gear and loading changes.
OIL Oil Pressure This indicates the engine oil pressure in the units (PSI/IN/KPA/MM)
as selected in the setup procedure
LOD Engine Loading This is a percentage of the maximum power available currently
being generated. In some vehicles it is the maximum available at the
present RPM.
HPR Horsepower Displays the calculated Horsepower your vehicle is currently making.
This value can be adjusted for accuracy through the Advanced Setup
parameters (see page 14).
Add Custom Gauges
The ScanGauge features the exclusive X-GAUGE™ programmable gauge system
allowing you to add custom, vehicle specific gauges to the digital gauge set.
For an overview of the X-GAUGE™ system, see page 41. For an up-to-date list of known X-GAUGE™ codes, visit us
online at: www.ScanGauge.com/support
Operating Your ScanGaugeD
27
