Manual and declaration of the manufacturer - electromagnetic resistance
The birthing bed AVE 2 is intended for use in electromagnetic environment. The customer or user of the birthing
bed must ensure that the bed is used in such environment.
Resistance Test
Test Level as per
IEC 60601
Level of Compliance
Electromagnetic
Environment
Electrostatic
discharge (ESD)
IEC 61000-4-2
± 6 kV for contact
± 8 kV for air
± 6 kV for contact
± 8 kV for air
Ensure that the following
requirements are met: Floors:
wood, concrete or ceramic
tiles Relative humidity: >30%
Electrical fast transient
response/
group of impulses
IEC 61000-4-4
± 2 kV in feeder line
± 1 kV in input/output
line
± 2 kV in feeder line
± 1 kV in input/output
line
Ensure the mains quality is
suitable for a commercial or
hospital environment.
Shock pulse
IEC 61000-4-5
± 1 kV between
lines
± 2 kV between line
(lines) and earth
± 1 kV in differential
mode
± 2 kV in co-phasal
mode
Ensure the mains quality is
suitable for commercial or
hospital environment.
Short-time voltage
drop, short-duration
interruptions
and slow voltage
changes on the feeder
input line
IEC 61000-4-11
<5 % U
T
(>95 % short-duration
drop of U
T
)
within 0.5 cycles
40 % U
T
(60 % short-duration
drop of U
T
)
within 5 cycles
70 % U
T
(30 % short-duration
drop of U
T
)
within 25 cycles
<5 % U
T
(>95 % short-duration
drop of U
T
)
within 5 s
<5 % U
T
(>95 % short-duration
drop of U
T
)
within 0.5 cycles
40 % U
T
(60 % short-duration
drop of U
T
)
within 5 cycles
70 % U
T
(30 % short-duration
drop of U
T
)
within 25 cycles
<5 % U
T
(>95 % short-duration
drop of U
T
)
within 5 s
Ensure that mains quality is
suitable for a commercial or
hospital environments. For
permanent operation during a
power failure, connect the bed
to a power generator as the
back-up battery’s capacity is
limited.
Magnetic field of
network frequency
(50/60 Hz)
IEC 61000-4-8
3 A/m
3 A/m
Ensure the magnetic fields of
the network frequency
conform to the normal levels
of commercial or hospital
environments.
NOTE U
T
refers to the AC mains voltage before the test level is applied.
