Linksys LAPAC1750PRO User Manual

83
Section 3: Configuring the Access Point
LAPAC1750PRO Access Point Software User Manual
NMS IPv4
Address/Name
Specify the IPv4 DNS hostname or subnet of the
machines that can execute get and set requests to the
managed devices. The valid range is 1-256 characters.
As with community names, this provides a level of
security on SNMP settings. The SNMP agent will only
accept requests from the hostname or subnet specified
here.
To specify a subnet, enter one or more subnetwork
address ranges in the form address/mask_length
where address is an IP address and mask_length is the
number of mask bits. Both address/mask and address/
mask_length formats are supported. Individual hosts
can be provided for this, i.e. IP address or Hostname.
For example, if you enter a range of 192.168.1.0/24 this
specifies a subnetwork with address 192.168.1.0 and a
subnet mask of 255.255.255.0.
The address range is used to specify the subnet of the
designated NMS. Only machines with IP addresses
in this range are permitted to execute get and set
requests on the managed device. Given the example
above, the machines with addresses from 192.168.1.1
through 192.168.1.254 can execute SNMP commands
on the device. (The address identified by suffix .0 in a
subnetwork range is always reserved for the subnet
address, and the address identified by .255 in the range
is always reserved for the broadcast address.)
As another example, if you enter a range of 10.10.1.128/25
machines with IP addresses from 10.10.1.129 through
10.10.1.254 can execute SNMP requests on managed
devices. In this example, 10.10.1.128 is the network
address and 10.10.1.255 is the broadcast address. 126
addresses would be designated.
NMS IPv6
Address/Name
Specify the IPv6 DNS hostname or subnet of the
machines that can execute get and set requests to the
managed devices.
Trap Community Enter the global community string associated with
SNMP traps. The valid range is 1-256 characters.
Traps sent from the device will provide this string as a
community name.
The community name can be in any alphanumeric
format. Special characters are not permitted.
Host Type Specify whether the enabled host is an IPv4 host or an
IPv6 host.
Hostname or
IP address
Enter the DNS hostname of the computer to which
you want to send SNMP traps. The valid range is 1-256
characters.
An example of a DNS hostname is: snmptraps.foo.com.
Since SNMP traps are sent randomly from the SNMP
agent, it makes sense to specify where exactly the traps
should be sent. You can add up to a maximum of three
DNS hostnames. Ensure you select the Enabled check
box beside the appropriate hostname.
NOTE:
After you configure the SNMP settings, you must click Save to apply the
changes. Changing some settings might cause the AP to stop and restart
system processes. If this happens, wireless clients will temporarily lose
connectivity. We recommend that you change AP settings when WLAN
traffic is low.
NOTE:
Hostnames are composed of series of labels concatenated with dots, as
are all domain names. Each label must be between 1 and 63 characters
long, and the entire hostname (including the delimiting dots) has a
maximum of 253 characters.

Linksys LAPAC1750PRO Specifications

General

Modulation	-
VLAN support	Yes
Frequency band	2.4, 5 GHz
Number of users	- user(s)
Channels quantity	- channels
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3ab, IEEE 802.3at, IEEE 802.3u
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1750 Mbit/s
Internal	No
Certification	FCC, CE, IC
Product color	White
Cable lock slot type	Kensington
Ethernet LAN (RJ-45) ports	2
Security algorithms	802.1x RADIUS, WEP, WPA, WPA2
Antenna gain level (max)	5.2 dBi
Input current	2 A
AC input voltage	12 V
Power consumption (typical)	24 W
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 35 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 85 %

Weight and Dimensions

Depth	238 mm
Width	247 mm
Height	43.3 mm
Weight	520 g
