Ground Control® 3.0
Aftermarket Manual
lci1.com (574) 537-8900 Rev: 04.19.18
CCD-0001307
Wiring Diagram - 4 Point
Hall Effect
Landing
Gear
Hall Effect
Landing
Gear
LCD Touch Pad Rear Sensor
Hall
Effect
Jack
Hall
Effect
Jack
4 Point
Controller
Battery
Touch Pad
Harness
Rear Sensor
Harness
Recommended
50 Amp Breaker
(not included)
