Ground Control® 3.0
Aftermarket Manual
lci1.com (574) 537-8900 Rev: 04.19.18
CCD-0001307
LCD Message What's Happening? What Should Be Done?
****ERROR****
Excess Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during auto operation. Relocate the trailer.
****ERROR****
Excessive Angle
Controller not properly secured. Check and secure controller placement.
Excessive angle reached during manual operation. Relocate the trailer.
****ERROR****
Feature Disabled
Front of trailer below level when starting Auto Level process
(only triggers when trying to initiate Hitch Recognition).
Using manual mode on the touch pad, retract rear jacks (which
includes the middle, if equipped) and set landing gear (front jacks) to
hitch height.
Touch pad power not cycled between consecutive leveling
operations.
Turn touch pad off and then back on to reset the system.
Zero point not set. Set zero point.
****ERROR****
Low Voltage
Battery voltage dropped below 10.8V.
Check wiring - repair or replace.
Test battery voltage under load - charge or replace.
****ERROR****
Out Of Stroke
Jack has reached maximum stroke length and is unable to
lift.
Check disposition of jacks. Relocate the trailer.
Unexpected high amp current stall.
Check jacks in manual mode or perform manual override procedure.
Repair or replace as needed.
Check for bent or damaged jacks. Repair or replace as needed.
****ERROR****
External Sensor
Bad connection or wiring from the controller to the rear
sensor.
Replace or repair connection to rear remote sensor.
****ERROR****
Jack Time Out
Time limit exceeded for the requested auto operation. Check disposition of jacks.
****ERROR****
Auto Level Fail
Unable to auto level due to uneven ground. Check disposition of jacks. Relocate the trailer.
Unable to auto level due to zero point being set incorrectly. Reset zero point.
****ERROR****
Comm Error
Communication between the controller and touch pad has
been lost.
Check harness for proper connections or damage. Repair or replace
as needed.
****ERROR****
Bad Calibration
Sensor calibration values are out of range. Replace controller.
****ERROR****
Internal Sensor
Internal sensor problem. Replace controller.
**PANIC STOP**
Function Aborted
The user pressed a button on the touch pad during an
automatic operation.
Restart automatic operation and then refrain from pressing any buttons
on the touch pad.
***ERROR****
Hall Effect Short
Short circuit detected in one of the hall effect circuits. Test for short. Repair or replace as needed.
Touch Pad
Note: To clear an error from the touch pad, repair or otherwise
correct the issue, then press “ENTER”. If the error is still
present, the message will be displayed again.
