Rev: 11.13.2017 Page 15
Ground Control TT Leveling OCTP Owner's
Hitch Recognition
1. Power on the OneControl Touch Panel App.
2. Press the "Leveler" icon (Fig. 12A).
3. Press "AUTO HITCH" (Fig. 9K).
A. Rear jacks will retract.
B. The Power Tongue Jack will extend to the ground.
C. Front leveling jacks will retract.
D. The tongue jack will then adjust the height of the front of the trailer coupler to the point at which
the “AUTO LEVEL” button was most recently pressed.
4. Back the tow vehicle into position to align the tow vehicle hitch and trailer coupler with each other.
5. Press "RETRACT" button, then press the "FRONT" button to retract the tongue jack until the coupler
sets into position on top of the tow vehicle hitch.
6. Latch the tow vehicle hitch and connect any wires, chains or sway control that may be equipped
between the tow vehicle and trailer.
7. Press the "RETRACT" button and then press and hold the "FRONT" button until the Power Tongue Jack
fully retracts.
NOTE: To utilize the Power Tongue Jack for the hitching process see "Operation - Power Tongue Jack."
Fig. 14
C
B
G
F
A
E
H
D
I
NOTE: When the OneControl Touch Panel is placed in Manual
Mode, the Linc remote will operate the jacks in a
similar fashion as the OneControl, with the exception
of operating individual jacks. Jacks will operate in pairs.
(See "Operation - OneControl Touch Panel").
Touch Panel Diagram - Linc Remote Control - Optional
Callout Description
A Retract - Retracts Power Tongue Jack.
B
Front Arrow - Operates Power Tongue Jack. (See Note
below)
C Left Arrow - (See Note below)
D Help - Provides contact information for LCI.
E Extend - Extends Power Tongue Jack. (See Note below)
F Right Arrow - (See Note below)
G Rear Arrow - (See Note below)
H Auto Level- Initiates Auto Level sequence.
I Power Button - Turns remote control on and off.
