LEVELING AND STABILIZATION
Hall Effect
Jack; Right
Rear
Hall Effect
Jack; Left Rear
GROUND CONTROL TT LEVELING OCTP ASSEMBLY
Leveling Jack (x2 or x4)
Tongue Jack Crank Handle
Power
Tongue Jack
Jack
Harness (x4)
Tongue Jack
Harness
Power and
Ground Harness
Leveling Sensor
Harness 35'
Leveling Sensor
Harness 15'
Nut
⁄
"
(x24)
Washer
⁄
" (x24)
Bolt
⁄
"
(x24)
Blue Controller HD
Green Controller SE
Canbus Power
Connector
Canbus Data Harness
Canbus Terminating
Resistor (x2)
OneControl
Touch Panel
4 Pin Pigtail Harness
Leveling
Sensor (x2)
Auto leveling
Control
Touch Panel
TT Leveling
Label
Unity Level Up Label
Ground Control Label
Leveling Sensor
Mounting Plate (x2)
Linc Remote (Optional)
#8 x 18 x1
Screw (x8)
