Lippert Components ground control TT Owner's Manual

Rev: 11.13.2017 Page 9
Ground Control TT Leveling OCTP Owner's
OneControl Touch Panel In Standard and Manual Modes
Standard Mode Features
• Press "EXTEND" (Fig. 4J) or "RETRACT" (Fig. 4I) and "FRONT" (Fig. 4A) to extend or retract the Power Tongue Jack.
• Press the "AUTO LEVEL" (Fig. 4M) button to start the auto leveling sequence.
• Press the "AUTO HITCH" (Fig. 4N) button to start the hitch recognition sequence when reconnecting to the tow
vehicle.
• Use the "UP" or "DOWN" arrow (Fig. 4B) buttons to cycle through the menu screen options:
A. Info: Scroll to "INFO" (Fig. 4C) and press "ENTER" (Fig. 4H) button to display system information, e.g.,
angle, jack stroke or software version.
B. Auto Retract: Scroll to "AUTO RETRACT" (Fig. 4F) and press "ENTER" button to start the "Auto Retract"
sequence, which will retract all jacks. The Power Tongue jack does not retract.
C. Manual Mode: Scroll to "Manual Mode" (Fig. 4G) and press "ENTER" button to start Manual Level
operation.
Manual Mode Features
NOTE: Upon entering Manual Mode, a tutorial on operating the jacks will appear on the screen. Press "OK" to clear
the tutorial. To delete the tutorial, click the "Don't show this again" box in the bottom right of the screen.
• Press "EXTEND" (Fig. 7F) or "RETRACT" (Fig. 7E) and "FRONT" (Fig. 7B) to operate front jacks.
• Press "EXTEND" or "RETRACT" and "REAR" (Fig. 7D) to operate rear jacks.
• Press "EXTEND" or "RETRACT" and "RIGHT" (Fig. 7C) to operate right jacks.
• Press "EXTEND" or "RETRACT" and "LEFT" (Fig. 7A) to operate left jacks.
NOTE: To operate jacks individually, press "EXTEND" or "RETRACT" then press the “LEFT” (Fig. 7A) or “RIGHT” (Fig.
7C) button while simultaneously pressing the “FRONT" (Fig. 7B) or "REAR” button (Fig. 7D), depending on
which jack needs to be operated.
NOTE: If the jacks will not operate individually using the method described above, but they operate properly when
Auto Level is performed, the Twist Prevention Protection system has locked out the operation to prevent
damage to the frame of the trailer.
Unhitching From A Tow Vehicle
NOTE: Prior to unhitching from the tow vehicle, ensure trailer is parked on a level surface and chock the tires of the
trailer.
NOTE: Ensure the foot pad of the Power Tongue Jack is pinned securely in place with the clevis pin and hairpin cotter
pin.
1. Disconnect any wires, chains, or sway control that may be equipped between the tow vehicle and the trailer.
Unlatch the trailer coupler.
2. Press "EXTEND" and "FRONT" button (Fig 4A) on the OneControl Touch Panel in Standard Mode to extend the
Power Tongue Jack until the foot touches the ground and the coupler clears the hitch ball.
NOTE: If using the OneControl Touch Panel and the hitch is not visible a second person will be needed to monitor
the operation of the unhitching process.
3. Disconnect the trailer wire connection at the tow vehicle, if not previously completed.
4. Pull tow vehicle away and park at a safe distance.
NOTE: To utilize the Power Tongue Jack for the unhitching process see "Operation - Power Tongue Jack."
Auto Leveling
1. Prior to auto leveling, ensure the trailer is unhitched from the tow vehicle and the tow vehicle is parked a safe
distance away from the trailer.
2. Press the “ON/OFF” button (Fig. 4L) if the OneControl Touch Panel is not on.
3. Press "MyRV Control Panel" on the main screen (Fig. 5A).
4. Press the "Leveler" icon (Fig. 6A).
5. Press “AUTO LEVEL” (Fig. 4M).
