4
ESD PROTECTION
Potential Damages Caused by Exposure to ESD
To prevent electrostatic discharge (ESD) damage to LectroCount register electronic components, all LectroCount
electrical system).
Epson printer.
Liquid Controls’ Grounding Kits
seats allow static electricity to “bleed off” the driver and the seat before it can build up, discharge, and damage the
The LectroCount Ground Strap Kit will be included with all future LCR-II LectroCount register shipments, and the
ESD Procedural Precautions and LectroCount Register Grounding
Installation Notes
followed to safeguard against ESD damage.
REGISTERS NOT MOUNTED DIRECTLY TO THE METER
In typical LectroCount installations where the LectroCount register is mounted directly to the meter, the LectroCount
LectroCount housing is grounded properly.
Alternate grounding method
1 ohm). Use a 12ga. or larger stranded wire.
FIXED INSTALLATIONS
require metal conduit to the conduit hubs for the wiring. The metal conduit provides the necessary ESD protection.
Divison 2 installations can ground the LectroCount housing by using shielded cables (or wiring) run through liquidtite
installations require and additional grounding method to ensure a proper ground.
1 ohm). Use a 12ga. or larger stranded wire.
Follow this procedure each time you open a LectroCount register or approach a LectroCount register with the door open.
Before opening the LectroCount register and handling the CPU board, it is important to discharge any ESD that may have built up on
your person. To discharge ESD from your person, touch a well-grounded point such as the LectroCount register housing, the meter,
the truck piping, or the bumper. When the maintenance is complete and the LectroCount register door is closed, the CPU board is
protected from ESD by the LectroCount register housing which is grounded to the chassis.
. ESD Precaution .
Opening LectroCount Registers
