3.2. Layout of the elements
Depending on the diameter of the bars to be guided, choose the appropriate diameter of the guiding
elements; assemble the pusher according to the chart below.
Important: The performance of the guidance may be determined by the clearance between the bar
diameter and the guiding elements.
LP
Cone
Collet
