2-2 CHAPTER 2: TECHNICAL DATA
ALPHA 552
1. CHARACTERISTICS
NOTE : Depending on the options, these technical data may vary. Please refer to the technical
data sheet.
3 meter 12 foot 4 meter
Weight
650 kg 700 kg 750 kg
Dimensions
See Floor Plan, page 2-3
Minimum diameter
(profiled: on flats)
5 mm
(square: 4 mm)
(hexa: 5 mm)
5 mm
(square: 4 mm)
(hexa: 5 mm)
5 mm
(square: 4 mm)
(hexa: 5 mm)
Maximum diameter
ALPHA 538: 38 mm
ALPHA 552: 52 mm
Minimum bar stock length
1000mm
Maximum bar stock length
3200 mm 3800 mm 4200 mm
Minimum remnant length
90 mm
Maximum remnant length
400 mm
Pneumatical pressure
5 bar
Air consumption
< 10 liter / loading cycle
Main electrical power
3x 220 – 480 V
50 Hz – 60 Hz
Max. 6A
Pushing force
Nominal: 464N
Max. electrical: 1160N (0,5 seconds) + 630N with mechanical booster
Maximum feed rate
>1m/min
Loading cycle
35 - 40 seconds
Hydraulic oil
ISO 100 / 50 liters ISO 100 / 50 liters ISO 100 / 50 liters
2. FLOOR PLAN
Left to right bar feeder (LtoR) Right to left bar feeder (RtoL)
Lathe
Lathe
