CHAPTER 7: OPERATION 7-27
QUICK LOAD SERVO III MI
4. Options
1. Barfeed with profiled bar guide (no/yes)
2. Barfeed with telescopic pusher (no/yes)
5. Interface
(standard
parameters)
These parameters set the communication and working mode between the lathe and the barfeed.
PI00
PI02
PI03
PI04
PI05
PI06
PI09
PI10
PI11
PI13
PI14
PI15
PI16
PI17
PI18
PI19
PI20
PI21
PI22
PI23
PI24
PI26
PI27
PI30
PI31
PI32
PI33
PI34
PI35
PI36
PI37
PI39
PI40
PI41
PI42
6. Working
mode setup
1. Barfeeder in : Working mode (normal operation)
2. Simulation
3. Demo mode
4. Interface simulation with lathe, without bar
7. Applications
display
1. Parameter access: Sub-spindle (no/yes)
2. Parameter access: One shot shaft loading (no/yes)
3. Parameter access: Loading with fixed spindle liner (no/yes)
4. Parameter access: Use the pusher as mechanical stop (no/yes)
5. Parameter access: Dry run function (no/yes)
6. Parameter access: Turret waits in position or follows bar (no/yes)
7. Parameter access: Feed out to part length with or without M-code (no/yes)
8. Parameter access: Sub-spindle: fixed or sliding headstock (no/yes)
9. Parameter access: End of bar (yes/no)
10. Parameter access: Top-cut position (no/yes)
11. Parameter access: Clamping device signal inversion (no/yes)
12. Parameter access: Position of loading flag (no/yes)
13. Parameter access: Bar length: variable or constant (no/yes)
14. Parameter access: Production selection (no/yes)
15. Parameter access: Feed rate for part feed out (no/yes)
8. Network
settings
1. Ethernet Interface (disabled/enabled)
2. Ethernet interface type (1: MTCONNECT / 2: OKUMA / 3: MORI SEIKI / 4: MAZAK)
3. CPU – IP Address
4. CPU – Subnet mask
5. CPU – Default gateway
6. ANYBUS – IP Address
