CHAPTER 7: OPERATION 7-7
QUICK LOAD SERVO III MI
3. SET UP
Please read the safety instructions provided at the beginning of this manual before
handling the following devices.
All handling, optional accessories and settings required by the bar feed system to carry out a specific job
are part of the set-up.
A few simple operations are necessary to prepare the device to handle another range of diameters.
The set-up must be modified when following parameters change:
• Bar stock diameter
• Bar stock shape
• Part length
3.1. Barfeed mechanical setup
3.1.1. Pusher adaptation
Please read the safety instructions provided at the beginning of this manual before
handling the following devices.
Depending on the bar stocks to feed, a changeover of the pusher may be necessary. In this case, please
refer to CHAPTER 6, section 5.2. Pusher replacement of this user manual.
