LNS QUICK LOAD SERVO III MI - Layout of the Elements

CHAPTER 2: TECHNICAL DATA 2-5
QUICK LOAD SERVO III MI
3. LAYOUT OF THE ELEMENTS
Designation Description
A Protection grate
B Loading magazine
C Magazine slope adjustment
D Retraction system
E Electrical control
F Access door
G Air filtering unit
H Interface plug (acc. to OEM requirements) (not shown here)
I Remote control (not shwn here)
J Carrier
K Feeding pusher (not shown here)
L Loading table
M Loading fingers
A
B
D
E
F
G
J
M
L
