7-34 CHAPTER 7: OPERATION
QUICK LOAD SERVO III MI
5
[SET]
The remote command displays the following text : "END OF BAR POSITION".
Press the key attributed to the icon [SET].
Depending on which sequence the bar feed is in when the parameter is selected,
the available functions and icons can change :
Conditions
Functions
By offset correction By teaching
- Loading channel down
No bar stock in the loading channel
Icon [+/-] Icon [TEACH IN]
-
Loading with extended loading
pusher
Icon [+/-]
---
Setting by offset correction: jump to point 6
Setting by teach in: jump to point 7
6
[+/-]
[+/-] by offset correction:
• press the key corresponding to the icon [+/-].
• the current end of bar position (z) is displayed.
• enter with the direction keys the correction to insert, and press the [+]
icon to add the value, or the icon [-] to subtract it. the new value is
stored.
• to exit the end of bar set mode, press the key attributed to the icon
[ESC].
jump to point 8.
7
[TEACH IN]
[FWD]
[ENTER]
[TEACH IN] By teaching:
• Press the key attributed to the icon [TEACH IN]. The display shows the
current end of bar position.
• Press the key [FWD] and advance the pusher to the desired position
(see previous page).
• To validate the new end of bar position, keep [ENTER] pressed until the
icon disappears.
8
[ESC]
or
[STOP]
To exit the set mode, press the keys [ESC] or [STOP].
