14
When the top cutter's bearing housing is
adjusted, or when the planing knife's cut is
changed, the counter's pre-set must be height
calibrated.
ADJUSTMENT OF THE TRAPEZOIDAL
THREADED BAR'S CHAIN TRANSMISSION
The chain, which raises and lowers the table, must
not be slack, but needs to be tensioned enough that
teeth bite correctly. The tension is set using a nut
that is located in the chassis under the planer table
on the outfeed side.
Do not touch the chain tension as long as the
raising and lowering of the table works, as an
incorrect tension could mean that the chain
disengages.
