20
VARIABLE FEED MOTOR INSTRUCTION
WARNING! Do not turn the adjustment knob when
the planer/moulder is not running.
ASSEMBLY (IF THE VARIABLE FEED MOTOR
IS ASSEMBLED IN PLACE).
Assemble the feed motor package on the last feed
roller. Make sure that the torque stay is in place.
Lock this with the central screw on the roller.
SETTING THE FEED SPEED
Turn the wheel clockwise to increase the speed.
INDICATOR DIAL FOR THE FEED SPEED
The indicator dial is/must be mounted in the hub
of the wheel. It works like an indicator that has a
weight in one part, so the indicator moves. The
black indicator shows a gure.
The indicator dial has a relative scale. See the num-
bers as an indicator. The higher the number, the
greater the speed.
Start the planer/moulder and turn the wheel so the
planer reaches minimum speed.
Remove the indicator dial and turn it so the indicator
is set to zero. Then press the indicator dial in with
the indicator pointing upwards towards zero.
Use the indicator dial so that you can return to the
best speed for the prole you are planing.
If you have a 3-15 m/min (10-49 ft/min) gear:
0 on the indicator dial is 3 m/min (10 ft/min)
8 on the indicator dial is 15 m/min (49 ft/min)
If you have a 6-30 m/min (19 1/2-98 ft/min)
gear:
0 on the indicator dial is 6 m/min (19 1/2 ft/min)
8 on the indicator dial is 30 m/min (98 ft/min)
MAINTENANCE
Fluid should be visible in the uid level glass. The
level is checked when the planetary gear is not
running.
Top up if no uid is visible in the glass. Use oil for
automatic gearboxes according to the table below,
or use compatible oil.
The variator is lled with AGIP BLASIA 32 at the
factory and does not normally require an oil change
during its life.
The worm gear oil does not normally need changing
or topping up during the life of the gear.
AGIP BLASIA 32
SHELL A.T.F DEXRON
ESSO A.T.F DEXRON
MOBIL A.T.F 220
CASTROL DEXTRON II
BP AUTRAN DX
