LOGOSOL PH360
TECHNICAL DATA
PH360
Length and width: 2,970 x 1,125 mm (117" x 44")
Height 1,430 mm (56")
Weight 600 kg (1322 2/10 lbs)
4-SIDED MOLDING
Width 360 mm (14")
Height 10-130 mm (4/10"-5")
2-SIDED MOLDING
Width 410 mm (16")
Height 10-230 mm (4/10"-9")
PLANING (assembly required)
Width 510 mm (20")
Height 230 mm (9")
TOP HORIZONTAL CUTTER
Diameter 88 mm (3 5/10")
Width 510 mm (20")
Output 5.5 kW (7.5 Hp)
Rotational speed 6,000 rpm
Cut when planing: 0-8 mm (0-3/10")
Cut when molding Max. 20 mm (8/10")
BOTTOM HORIZONTAL CUTTER
Diameter 72 mm (2 8/10")
Width 410 mm (16")
Output 4 kW (5.5Hp)
Rotational speed 6,000 rpm
Cut when planing: 0-8 mm (0-3/10")
Cut when molding Max. 10 mm (4/10") (Slot milling: 15 mm 6/10")
SIDE CUTTERS
Diameter of spindle axel 30 mm (1 2/10")
Cutter height Max. 130 mm (5")
Diameter Max. 140 mm (5 5/10")
Output 3 kW (Hp)
Rotational speed of side cutters 6,000 rpm
Cutting depth Max. 30 mm (1 2/10")
SUPPLIED SIDECUTTERS
Type and quantity 2 x TB90
Diameter, body 90 mm (3 5/10")
Height, body 40 mm (1 6/10")
Cut, type and width Planing knife HSS, 50 mm (2")
FEED, PLANED VARIATOR
Output 0.75 kW (1 Hp)
Feed rate 3-15 m/min or 6-30 m/min (10-49 ft/min or 19 1/2-98 ft/min)
ELECTRIC SYSTEM
Total output 16.25 kW (22 hp) All motors are equipped with overheating protection.
Electrical connection 3-phase, 400 V, 32 A, 20A fuses are sufcient for less demanding production.
