30
LIST OF COMPONENTS
Pos. Description Quantity Ref. no.
1 Cast Iron Table 1 7536-001-0001
2 Plastic Slide Strip,
Feed Rollers 2 7536-001-0002
3 Plastic Slide Strip,
Top Cutter 1 7536-001-0003
8 Chip Duct,
Bottom Cutter 1 7536-001-0008
14 Motor,
Bottom Cutter 1 7502-001-2340
14 Motor, Bottom
cutter, USA 1 7502-001-2606
21 Belt Pulley,
Bottom Cutter 1 7502-001-0300
26 Belt Pulley, Bottom +
Side Cutter 2 7502-001-0154
27 Poly-V Belt, Side
Cutter, 8 tracks 2 7500-001-2005
28 Motor, Side Cutter
400/230V 2 7502-001-0350
28 Motor, Side Cutter,
USA 2 7502-001-0605
29R Spindle, Cutter 1R 1 7536-001-029R
29L Spindle, Cutter 1L 1 7536-001-029L
29L+R Ball Bearing, Side
Cutter, Top Bearing 2 7502-001-0052
29L+R Ball Bearing, Side Cutter,
Bottom Bearing 2 7502-001-0152
30 Universal Cutter,
TB9092, 2 knives 2 7000-000-9092
31R Nut, Spindle 1 R 1 7502-001-0010
31L Nut, Spindle 2 L 1 7502-001-0030
32 Spacer 5 mm 2 7502-001-0046
32 Spacer 10 mm 2 7502-001-0044
32 Spacer 20 mm 2 7502-001-0042
32 Spacer 40 mm 2 7502-001-0038
34 Fence 2 1 7536-001-0034
35 Fence Bracket 2 7502-001-0098
36 Micro Adjustment,
Side fence 2 7502-001-0080
37 Chip Guard Plate 1 7536-001-0037
38 Locking Screw, Slide 1 7536-001-0038
52 Lock Handle, adjustable
M10 Inv. Thread 2 7536-001-0052
54 Bottom Cutter 1 7536-001-0054
55 Ball Bearing,
Bottom Cutter 2 7502-001-0152
56 Bearing Bracket,
Bottom Cutter 2 7502-001-0146
56 Seal O-ring,
Bottom Cutter 2 7502-001-0120
Pos. Description Quantity Ref. no.
57 Belt Pulley motor,
Bottom Cutter 1 7502-001-0154
60 Moulding Knife,
410 mm 2 7000-002-8410
61 Chip Breaker,
410 mm 2 7502-001-0140
67 Poly-V Beltv, Bottom
Cutter, 8 tracks 1 7500-001-2007
70 Bronze Bushing,
Slide 1 7536-001-0070
74 Slide 1 7502-001-0062
76 Pressure Roller,
complete 1 7502-001-0178
77 L Bracket, Complete 1 7536-001-1077
78 Pressure Roller,
Front/Back, Compl. 3 7536-001-1084
90 Bracket, L Bracket 1 7502-001-0213
90B Lock Fitting,
L Bracket 1 7502-001-0212
91 Locking Handle,
Adjustable, M8x20 1 7536-001-0091
94A Chip Duct,
Fixed Cutter 1 7536-001-094A
94B Chip Duct,
Movable Cutter 1 7536-001-094B
108 Cover Plate,
Metre Counter 1 7536-001-0108
109A Digital Counter,
Side Cutter 1 7536-001-109A
109B Metre Counter,
Height Adjustment 1 7536-001-109B
109C Inch Counter, USA 1 7536-001-109C
109D Inch Counter, USA 1 7536-001-109D
122 Chain 1, Feed 1 7536-001-0122
123 Chain Sprocket,
Rollers 8 7536-001-0123
124 Chain M1, M2 1 7502-001-0180
125 Chain 3, Feed 1 7536-001-0125
126 Chain 4, Feed 1 7536-001-0126
128 Top Cutter 1 7536-001-0128
129 Bearing, Top Cutter 2 7502-001-0052
130 Bearing Bracket,
Top Cutter, 2 7536-001-0130
130 O-Ring, Top Cutter 2 7536-001-0716
131 Belt Pulley, Top Cutter
Spindle 1 7536-001-0131
133 Moulding Knife 510mm,
HSS, 510x25x3 mm 2 7000-002-8510
134 Chip Breaker,
510 mm 2 7536-001-0134
To Next Page
