TR700 Instruction Manual
34
zero response
Filtering coefficient
Range of dynamic
detection Checking
Accumulati
on
Unit setting Display updating rate
Conditions of
comparison output Sampling rate
Checking Accumulati
on
The meanings of the parameters are referred to Table 5-1.
 Description of Status Word of Response：
= 0xaa, Successful;
= 0x55, Failed.
6.4.3.3.21. Set the Parameters of DIDO Distributor
Request：Master Response：Slaver
Domain name Data（hex） Domain name Data（hex）
Beginning code 7E Beginning code 7E
Address 01-63 Address 01-63
Function code 31 Function code 31
Length of data
4
Length of data
1
Distribution of input
2 Distribution of input 1
Status of
response
Distribution of input
4 Distribution of input 3
Checking
Accumulati
on
Distribution of
output 2
Distribution of output
1
Distribution of
output 4
Distribution of output
3
Checking Accumulati
on
The meanings of the parameters are referred to Table 5-1.
 Description of Status Word of Response：
= 0xaa, Successful;
= 0x55, Failed.
6.4.3.3.22. Set the Parameters of Serial Port 1
Request：Master Response：Slaver
Domain name Data（hex） Domain name Data（hex）
Beginning code 7E Beginning code 7E
Address 01-63 Address 01-63
