Note:
Network mode are used to change how a group EVSE connecting to the internet. If a charge point’s
network mode is Client, then there must be a Gateway in this group and all client charge points are con-
nected to the internet via Gateway. These chargers form a Gateway/Client group. In this group there is
exact one Gateway and all other charge points are Client.
Gateway LAN IP: The IP of master in LAN. This value cannot be modied by users.
Gateway LAN Port (SOAP): The listen port for OCPP SOAP client server. This value cannot be modied
by users.
Max Group Size: The maximum number of Loop EV-Flex EVSEs allowed in a group/LAN. This value cannot be
modied by users.
Gateway Serial Number: The serial number of the Loop EV-Flex EVSE which acts as a Gateway.
Group Use External Gateway: Gateway/Client mode use external gateway as a local network group or not (use
Gateway LOOP EV-Flex EVSE).
