4.2 Installing basket system
Prerequisite:
The relevant basket has been removed from the appliance.
4.2.1 Installing a tab slide for the 86 cm model
Required tools:
Tabguide [00614935]
Cup support clip [00618565]
1. Insert the tab slide diagonally at the front of the basket.
2. Centre and click the tab chute into place.
4.2.2 Installing cup support clip
Required tools:
Tabguide [00614935]
Cup support clip [00618565]
When washing cups, the cup support clip can be folded up. The addi-
tional angle reduces the collection of water on the bottom of cups. In the
case of tall glasses we recommended leaving the cup support clip folded
down.
If upper baskets have an optional plastic insert, they must first be re-
moved.
1. Remove the plastic insert.
2. Click the cup support clip into place.
3. Fold up the clip.
