4. Lift overflow conduit off.
4.16.2 Installing overflow conduit
Water damage due to incorrect installation of the overflow conduit!
Correctly insert the overflow conduit at the bottom into the guide of the
base trough.
Click the overflow conduit correctly into place at the top.
1. 1. Place overflow conduit (1).
2. Move overflow conduit into seal (2).
3. Press overflow conduit in guide of seal (3).
4. Insert overflow conduit concisely (4).
5. Clip in overflow conduit (5).
