4.14 Replacing toe panel
The feet are identical and can be swapped over.
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Outer door has been removed.
Outer door has been removed (fully integrated/integrated).
4.14.1 Removing toe panel
1.
Incorrect removal.
If the toe panel is loosened at the side and removed, the two brack-
ets may break away. If only one bracket is damaged, the side can be
changed as the brackets are identical.
It is advisable to place something under the appliance at the front on
the side to relieve the load on the toe panel with the feet.
2. Reach into the guides (1) with a screwdriver and release the catch by pushing
downwards.
3. Lift the panel off.
4. Remove the feet forwards (1).
4.14.2 Installing toe panel
1. Insert the feet.
2. Attach the toe panel at the top (1) and press it down until it audibly clicks into
place (2).
