LORD D1 - Replacing Side Panel

4.10 Replacing side panel
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Appliances is freely accessible.
Free-standing appliances: Worktop has been removed.→Page 214
4.10.1 Removing side panel
1. Remove screws from the side panel (1).
Fig.1: Fully integrated
2. Tilt the side panel slightly outwards at the top (2).
3. Lower the side panel and pull it out of the base trough (3).
