4.8 Replacing detergent cover
A small screwdriver can be used as a levering tool.
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Door has been opened.
Detergent cover has been opened.
4.8.1 Removing detergent cover
1. Slide the detergent cover in 5 mm.
2. Lever the detergent cover on the lower side out of the guide rails and take the de-
tergent cover on the upper side out of the guide rails.
3. Remove the spring.
4.8.2 Inserting spring
1. Insert the long end of the spring into the mounting hole of the dispenser device (1).
2. Insert the short end of the spring into the mounting hole of the detergent cover (2).
3. Press cover into the dispenser device (3).
4.8.3 Installing detergent cover
1. Insert the detergent cover 5 mm before the completely open position into the guide
rails on one side. Applying gentle force, press the opposite side into the guide
rails.
2. Check the function of the detergent cover.
