4.23 Replacing Gap illumination
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Outer door is disassembled.
Operation panel has been removed.
4.23.1 Removing Gap illumination
1. 1. Detach catch (1).
2. Remove electrical connection from the operation module (2).
2. 1. Detach catch hook at rear (1).
2. Remove light fibre (2).
