LORD D1 - Replacing overflow conduit; Removing overflow channel

4.16 Replacing overflow conduit
The overflow conduit is located in the front lower area of the appliance.
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Furniture panel has been removed (optional).
Outer door has been removed.
Toe panel has been removed (optional).→Page 232
Base socket plate has been removed.→Page 233
4.16.1 Removing overflow channel
Residual water
¡ When the drainage hose is removed, residual water may run out.
¡ Catch water or remove from the base pan with suction syringe.
1. Lever out of the catch mechanism at the top (1, 2).
2. Release catch element at top.
3. 1. Insert screwdriver below metal brake (1).
2. Gently release metal clip (2).
