4.21 Replacing EmotionLight
The EmotionLight is situated in the upper front exterior area of the rinsing
tank.
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Appliances is freely accessible.
Worktop has been removed (optional).
The right-hand side panel has been removed (optional).→Page 225
4.21.1 Removing EmotionLight
1. Detach catch hook at the rear (1).
2. Remove the holder upwards (2).
3. Pull plug out of connector (bottom right at front of appliance).
4. Remove electrical connection from the power module.
5. Remove EmotionLight from the appliance.
4.21.2 Installing EmotionLight
1. Insert the holder into the rinsing tank frame (1).
Repair
