4.4 Replacing spray arms
4.4.1 Removing spray arm
1. Unscrew the upper spray arm (1) and pull down to remove (2).
1
2
2. Pull down the lower spray arm to remove.
4.4.2 Installing spray arm
1. Insert the lower spray arm.
The spray arm clicks into position.
2. Insert the upper spray arm and screw it firmly in place.
