Repair
4.1 Replacing worktop
Prerequisite:
Appliance is disconnected from the power supply.
Appliance is freely accessible.
4.1.1 Removing worktop
1. Remove the two screws at the back (1) (optional).
2. Press both catch levers under the worktop upwards (2).
3. Lift the worktop slightly at the front (3).
4. Push worktop away towards the rear (4).
5. Remove worktop.
4.1.2 Installing worktop
1. Lock the rear of the worktop into the guides using the retaining collars (1).
2. Push worktop forwards (2).
3. Press the front of the worktop downwards until both catch levers click audibly into
place (3).
4. Screw in the two screws again (4) (optional).
