4.22 Replacing TimeLight
Replace the TimeLight only as a complete part.
The TimeLight module is fixed to the rear of the base socket plate.
Prerequisite:
Appliance is disconnected from power supply.
Appliance is disconnected from water supply.
Toe panel has been removed.→Page 232
Base socket plate has been removed and turned.→Page 233
4.22.1 Removing TimeLight
1. Bend the catch elements (1) slightly outwards.
2. Pull the TimeLight module upwards out of the guide (2).
4.22.2 Installing TimeLight
1. Bend the catch elements (1) back again.
2. Push the TimeLight module into the guide (2).
3. Connect the electrical connection.
