Using the On–Screen Display
7
1. Instant Playback: Plays back recent video from the selected channel. By default, instant play-
back is set to play the last 5 minutes of recorded video. See 14.7.1 Configuring General Sys-
tem Settings, page 64 to set a custom playback length.
2. Digital Zoom: Click to enable digital zoom. Click-and-drag over the camera image to zoom
in on the selected area. Right-click to return to the full camera image. You can then repeat to
zoom in on a different area, or click the icon again to disable zoom.
3. Real-time Backup: Click to start recording the current channel manually. Click again to stop
recording and save the video file to a USB flash drive (not included).
4. Snapshot: Save a snapshot of the current camera image to a USB flash drive (not included).
5. Mute/Unmute: Click to mute/unmute listen-in audio.
6. Warning Light — Deterrence Cameras Only: Click to manually turn on the camera’s warn-
ing light for 10 seconds.
7. Siren — Deterrence Cameras Only: Click to manually turn on the camera’s siren for 10
seconds.
7.4 On-Screen Keypads
The Full Keypad is used to input alphanumeric characters, such as in user name or password
fields. The Number Keypad is used to input numeric characters only, such as in the time or date
fields.
To use the Full Keypad:
• Using the mouse, click on a field where alphanumeric characters are entered, such as the user
name and password fields.
• The Full Keypad opens:
• Click Shift to switch between uppercase and lowercase characters.
• Right-click to close the Full Keypad.
To use the Number Keypad:
• Using the mouse, click on a field where numeric characters are entered, such as the date or time
fields.
• The Number Keypad opens:
• Right-click to close the Number Keypad.
#LX400111; r. 1.0/55872/56018; en-US 17
