Using the Main Menu14
To access the Online Users menu:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click INFORMATION. Click the NETWORK tab on the side panel, then Online User on
the top panel.
14.10.6 Load
The Load menu shows you the network traffic your system is sending and receiving.
To access the Load menu:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click INFORMATION. Click the NETWORK tab on the side panel, then LOAD on the top
panel.
14.10.7 Network Test
The Test menu allows you to test if your system can connect to other devices over the LAN or In-
ternet. You can enter the IP address of a device and click Test to determine if your system can con-
nect to it.
To access the Network Test menu:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
#LX400111; r. 1.0/55872/56018; en-US 78
