Replacing
the
Hard
Drive
19
3.
Turn
the
recorder
over
carefully
,
then
remove
the
top
panel.
CAUTION
The
wiring
to
the
front
panel
button
and
USB
port
runs
along
the
top
panel
of
the
recorder.
When
separating
the
top
panel,
rest
it
carefully
beside
the
bottom
panel
as
shown
below
.
#LX40011
1;
r
.
1.0/55872/56018;
en-US
91
98
100
