Lorex LH156 User Manual

3
5 PTZ/ :
• Within system menus: Press to confirm a selection.
• In Viewing mode, press to open the System Information window.
• In Viewing mode, press and hold for 6 seconds to open the PTZ menu.
6 USB P
ort: Connect a USB mouse (included) or USB flash drive (not included) for data backup
or firmware updates.
16-Channel
1 IR Sensor: IR receiver for the remote control.
LED Indicators:
• PWR: P
ower LED.
• HDD: Har
d disk activity LED.
2 Menu & Playbac
k Controls:
•
: In Playback Mode, press to rewind. Press repeatedly to increase rewind speed.
•
: In Playback Mode, press to play / pause video.
• In Viewing mode, press to open Search Menu to select playback time.
•
: In Playback Mode, press to fast forward. Press repeatedly to increase fast forward speed.
• : In
Playback Mode, press to stop video playback.
• In Live Viewing Mode, press to stop DVR recording. Password required; does not override
sc
heduled recording.
• Press and hold for 15 seconds to reset the DVR to the default resolution. DVR will reboot.
• :
Press to stop / resume recording. When the channel displays a red box with the letter "C",
the channel is recording.
• Menu / Esc: Open
s the system menu. In menus, press to go back / exit menus.
3 Channel Contr
ols:
• Ch
1 ~ Ch9: Press to view channel in Full-screen View.
• To access channels 10 and greater: Pr
ess 0 for channel 10 or 1+0 for channel 10, 1+1 for
channel 11, 1+2 for channel 12, etc.
• : In Live Viewing Mode, press repeatedly to switch between Split-screen Viewing modes.
3
1 2
4
5 6
