LHV2000 Series Hard Drive Installation
20
7. Replace the cover and cover screws (4x).
NOTE
After installation, you must format the hard drive in order to use it with the system. See 20.3 Format-
ting Hard Drives, page 151.
20.2 Removing the Hard Drive
20.2.1 LHV2104 / LHV2108 / LHV2116
CAUTION
Make sure that the system is OFF and ALL power adapters have been disconnected before removing/
installing the hard drive.
1. Power off the system, and unplug all cabling from the system.
2. Remove the rear panel screws (4x) and side panel screws (1x on each side). Re-
move the cover.
3. Turn the system over and loosen the hard drive screws (4x), but do not remove them.
4. Disconnect the SATA power and data cable from the hard drive.
5. Carefully turn the system over. Slide the hard drive and then lift it out of the system.
#LX400060; r.30328/35049; en-US
149
