Lorex N842A82 User Manual

Using the Main Menu17
17.5.3 BPS
Shows bitrates of connected cameras. The bitrate is the amount of data the camera is sending to
the system.
To access the BPS menu:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click INFORMATION, then click the Information tab on the side panel. Click the BPS
tab on the top panel.
17.5.4 System Log
Search for system logs in a certain time range.
To access the log menu:
1. From the Live View display, right-click to open the Quick Menu, then click Main Menu.
2. Click INFORMATION, then click the Log tab on the side panel.
17.5.5 Alarm
View a summary of active system alarms. Activated alarms are highlighted in white. Additional
info such as channels that are currently detecting motion is shown.
#LX400113; r. 9.0/57192/57197; en-US 67
