17
Com-1 wiring to receive NMEA position information from some other
GPS receiver
Com-1 wiring to transmit NMEA position information
to another NMEA-compatible device.
Ground
To Other
Device
Com-1
To GlobalMap
5300c
Y
ellow (Transmit)
NMEA Receive
Shield (Ground)
Orange (Receive)
NMEA Transmit
Shield (Ground)
Ground
Com-1
To GlobalMap
5300c
To Other
GPS Receiver
