(4) Turn signal lights, Lights, Horn
Check the operation status of light, turn signal
lights, horn etc.
If the light is OFF despite of operation of switch
of head light or indicating light,
1. Check the corresponding fuse in the fuse box.
2. If there is no problem in the fuse, check the bulb
of the corresponding light or change it.
Combination switch
Illuminating Lights
Headlights (low beam / high beam)
turn signal lights (front)
Side lights (front)
turn signal lights (rear)
Work lights
Indoor light
Instrument panel light & indicators
Light bulb specification
12V 55W / 60W
12V 16W
12V LED
12V 21W
12V 27W(Grille) / 37.5W(Cabin)
12V 10W(Cabin only)
LED
▶Use the bulb of rated capacity.
▶In case of using the improper bulb, it may cause a failure of electric system.
Notice
Brake lights / tail lights (rear) 12V LED / LED
(5) Engine coolant
Refer to the chapter 5-11-(1), “ Replacement of engine coolant “ (See page 5-27)
