6 -8
6-7. System diagram
Heater evaporator
Fan motor
Evaporator core
Heater core
Hot water
Control panel
Engine
Compressor
Fan
Radiator
Condenser
w/receiver drier
Cut-off valve
Expansion valve
Heater hose
Cooler hose
Electric line
