5 -25
(4) Replacing Cabin air filters
Before servicing the filters, switch off the blower
and close all cabin doors and windows.
Unscrew the bolts under the roof and remove
the cover and filter element as shown in the right
figure.
Clean both filter chambers with a damp, lint-free
cloth.
Replace the cabin air filters with a new one.
Re-install the filter cover and tighten the bolts.
▶ The filters are made of specially treated media with a rubber sealing strip bonded
around the sides. Take care not to damage the element during installation.
Notice
Cabin
air filters
Bolt
Filter
cover
To Next Page
