6 -3
6-3. Every 6 month check
(1) Checking refrigerant amount
Check the refrigerant amount periodically. Have to contact your authorized local dealer for it.
Refrigerant : R-134a, 850 ~ 900 g (30.0 ~ 31.7 oz)
The components of the air conditioning system have to be handled by authorized service expert.
(2) Cleaning Condenser and
Radiator screen
Stop engine and allow engine to cool. Open
bonnet and remove the radiator screen.
Wash the mud or foreign materials added to the
condenser and radiator screen with soft brush or
low pressurized air or water.
Pay attention that the cooling fin does not
damaged. If necessary, repair the distortion of
fin.
(4) Belt tension adjustment
Check the belt tension is proper and if necessary,
adjust the tension by compressor adjusting bolt.
Tension : approx. 10~12mm (0.4~0.5 in.)
(when pressed by 50N (11 lb))
Check the damaged part of the belt and if
necessary, after checking the pulley alignment,
replace it by a new one.
(3) Checking Leakage
Check the tightening torque and oil leakage state
of the connection parts.
If oil spot and foreign materials is added a lot, it
means that there is a leakage of refrigerant.
Check the refrigerant amount.
Tension
adjust bolt
Cut-off
valve
V-belt
Check point
Radiator screen
