5 -23
(2) Changing Transmission oil
Stop tractor on a level surface and apply parking
brake. Run engine for several minutes to warm
oil and lower implements and stop the engine.
Set container under drain plugs and remove the
drain plugs under the transmission and drain oil
completely.
Remove metal sludge stuck to drain plugs and
tighten the drain plugs again with copper washer.
Add new oil until the oil level is between MIN
and MAX of the oil gauge.
For oil specification, see chapter 5-3, “Lubricants
and Capacity” or the last page in this manual.
Drain plugs
▶ The contaminated oil may reduce the durability of transmission and cause the
failure of hydraulic system. Clean around oil filling inlet and oil gauge before
opening.
Caution
Oil filling inlet
Copper washer
Oil gauge
To Next Page
