LS tractor MT5 Series User Manual

3 -19
3-2. Right-hand controls and Cabin pillar
Important to owner, read carefully
Joystick lever
(Page 3-43)
Main gear
shift lever
Electrical power
outlet socket
4WD switch
Differential lock
switch
Wiper switch
Work light
switch
ECS switch
PTO mode
switch
Position control
lever
(Page 3-39)
Draft control
lever
(Page 3-39)
Remote control
Lever
(Page 3-42)
Auto lift switch
(Page 3-44)
Throttle lever
Parking brake lever
Throttle lever
(1) Throttle lever
 It is used to control the engine speed in field
operation. DO NOT use while driving on public
road. Use the throttle pedal at this time.
- Low speed : Pull the lever backward
- High speed : Push it forward.
 There is a sensitive electric sensor on the
throttle lever. Do not remove/modify it arbitrarily.
