5 -35
▶ If the main fuse is burn out often, contact your authorized local dealer to check the
problem.
▶ Do not use alternatives instead of the genuine fuse. And, do not connect electric
wire to the battery terminals directly. It may cause of the fire and serious injury.
Notice
③ Main fuse
Main fuse is attached inside start motor cover in
the left side of the engine for protection the
electrical circuit and components.
Disassemble the start motor cover.
Remove the fuse box cover, If necessary,
replace it with a genuine part.
Rated capacity : 60 A
The main fuse is an important part to protect the
total electric system of the tractor, if damaged,
check if there is a trouble in the electric system.
Contact your authorized local dealer for check.
Cover
Main fuse
Main fuse
