LS tractor MT5 Series User Manual

3 -36
SPN FMI Component Description
03 Shuttle lever sensor Short to PWR source
04 Shuttle lever sensor Short to Ground
02 Shuttle lever sensor & Neutral Switch Error
03 Clutch pedal sensor Short to PWR source
04 Clutch pedal sensor Short to Ground
100200 02 Clutch Button Clutch Button Error
100300 02 Rangeshift SW Rangeshift Switch Error
100400 02 Hi/Lo SW Hi/Lo Switch Error
100500 02 Calibration SW Calibration Switch Error
100600 02 Up/Dn SW Up / Down Switch Error
03 Signal PWR sensor Short to PWR source
04 Signal PWR sensor Short to Ground
16 Over the normal operating region (Signal PWR)
18 Below the normal operating region (Signal PWR)
03 Controller Power sensor Short to PWR source
04 Controller Power sensor Short to Ground
01 Below the normal operating region (Controller Power)
03 System Pressure sensor Short to PWR Source
04 System Pressure sensor Short to Ground
18 Below the normal operating region, least severe level (System Pressure)
00 Below the normal operating region, most severe level (System Pressure)
03 TM Oil temperature sensor Short to PWR source
04 TM Oil temperature sensor Short to Ground
- Over the normal operating region (TM Oil temperature)
- Below the normal operating region (TM Oil temperature)
110400 08 TM Speed Sensor TM speed sensor Error
05 Forward valve short to Ground
06 Forward valve short to PWR source
02 Over / Below the normal operating region (FWD valve current)
05 Reverse valve short to Ground
06 Reverse valve short to PWR source
02 Over / Below the normal operating region (REV valve current)
04 Hi/Lo valve short to Ground
03 Hi/Lo valve short to PWR source
04 Lub valve short to Ground
03 Lub valve short to PWR source
130100 19 No data from ECU Communication error with Engine Controller
120300 Lub Vavle
120000 Forward Valve
120100 Reverse Valve
120200 Hi/Lo Valve
110100
Controller Power
Sensor
110200
System Pressure
Sensor
110300
TM Oil Temp.
Sensor
100000 F/R Lever
100100 Clutch Pedal
110000
Signal PWR
Sensor
(6) Error Diagnosis Code (PSS) - continued
