This switch is used for operating front and rear
window wiper.
'A' in the figure means the neutral position of
switch and if you press 'B' position, the wiper
continues to operate.
- If you press 'B' position once more and hold it,
the washer liquid shall be sprayed out together
to wash the window. If you release the switch, it
returns to the 'B' position.
- If you press 'C' position, only washer liquid
shall be sprayed out.
(15) Window wiper switch (front, rear)
Front
window
wiper
switch
Rear
window
wiper
switch
▶
Use wind shield washer liquid for automobile in winter time.
▶
Do not operate the wiper without wind shield washer liquid, it may cause damage to
the wiper motor.
Caution
(16) Power out socket (Cabin only)
This is the socket for power withdrawal for the
charging of cigarette lighter jack or cellular phone.
In case of using cigarette lighter jack (option)
-If you push the cigarette lighter jack, the heating
coil generates heat and shall be used
as alternative of lighter.
In case of using as power supply (12V)
-Use the cellular phone charger less 10A.
Caution
▶
When using a cigarette lighter
jack, cares must be taken not to
touch the heating coil. The heat
generated coil is very hot and
may cause the danger of a burn.
3
3 3
3 - 6
(17) Indoor light (Cabin only)
Press the lower side of indoor light to turn on the
light.
Press the lower side of indoor light again to turn
off the light.
(18) Audio player (Cabin only)
Refer to the attached user’s manual for Audio
player.
▶
For safer operation, turn down the player volume so that you can hear sound from
outside tractor.
▶
Do not use the headset while driving the tractor.
Caution
Indoor
light
