Chapter 2 System Configuration
2-13
(2) 1:n Communication system
(a) Using RS-485 built-in function can connect between one computer and multiple main units for up
to 32 stations.
(b) Using RS-485 built-in function/expansion Cnet I/F module can be connect for up to 32 stations.
1) Refer to ‘XGB Cnet I/F user manual’ for details
Built-in RS-232C connection
Built-in RS-232C connection
To Next Page
