XGB Analog edition manual



9.11.2 Setting area of operation parameters
Memory
address
Description Setting value R/W Instruction
0 Enable CH Bit Off (0): disable, bit On (1): enable R/W
PUT/GET
1 Output range setting
Input range setting (4 bit per channel)
0: 4 ~ 20 ㎃
1: 0 ~ 20 ㎃
2: 0 ~ 10 V
R/W
2 Input data type setting
Input data type setting
(4 bit per channel)
0: 0 ~ 4000
1: -2000 ~ 2000
2: Precise value
3: 0 ~ 1000
- In case of precise value
4 ~ 20 : 400 ~ 2000
0 ~ 20 : 0 ~ 2000
0 ~ 10 V: 0 ~ 1000
R/W
8 CH output state setting
CH output state setting (4bit per channel)
0: Former value
1: min value
2: middle value
3: max value
R/W
11 Output CH0 gain weighting
-40 ~ 40
R/W
12 Output CH1 gain weighting R/W
13 Setup error information
50#: output ch range setting error
60#: output ch data type setting error
70#: output ch output state setting error
80#: output ch gain weighting setting error
90#: output ch input value excess error
(#: channel number)
R GET
9 - 24
